Input	Power Rating				5KVA	7.5KVA	10KVA	15KVA	20KVA	30KVA
	voltage range		v		400±20%
	Frequency		Hz		50±5%
	input power factor				>0.92
	charger Topology				BUCK-IGBT
	Electrical connection (sq.mm)		input		4	4	6	6	8	10
			output		4	6	8	12	16	25
			Batt	240V	6	10	12	12	16	NA
				360 V	6	6	8	12	12	16
			Earth & I/P-Nuet		2.5	2.5	2.5	2.5	2.5	2.5
Output	Power factor		lag		0.8
	voltage		V		220
	Voltage regulation		%		±1
	Frequency		Hz		50
	Frequency regulation		Hz		±0.05
	Waveform				Pure Sine Wave
	Transient Response		%		<8(10% ˜ 90%(Linear Load))
	Voltage Harmonic		%		<3(Linear Load)
	Over Load Capacity				100 to 150% : 18 Sec 150 to 300% : 20msec to 30msec >300 immediate
	Crest-Factor				3:1
	Receptacle				BS546,Screw Terminal
Audible Warning	Battery Back-up Ending				intermittent
	OverLoad				Continuous
Display	LED				UPS On # Battery High/Low # Overload # O/P High/Low # Chargin On # Mains Low/High.
Protection					Output Over Voltage# Output under Voltage# Overload# Output Short Circuit # Battery Over Voltage # Battery under Voltage.
	LCD Meter(16X1)				Input & Output Voltage & Frequency # Battery Voltage # Charging Current # Load Percentage(%)
Interface					RS232/USB Port,SNMP(Optional)
Others	Battery Start				Standard
	Cabinet Wheels				Standard
	Extended Battery Charging				Optional
	Static By Pass				Optional/Default Rotary Switch
Overall	Efficiency(AC/DC)		%		>90**(Full Load)
	Transfer Time		ms		0
	Temperature		° c		0 ˜ 45
	Humidity		%		5-95(Non-Condensed)
	Dimension	Width	Inch		11	11	11	13	19	22
		Heigth	Inch		21	21	21	27	30	33
		Length	Inch		24	24	24	31	33	34
