Input	Power Rating			25KV	30KV	40KV	50KV	60KV
	voltage range		v	400±20%
	Frequency		Hz	50±5%
	input power factor			>0.92
	charger Topology			BUCK-IGBT
	Electrical connection		input R,Y,B	10 Sq.mm	12 Sq.mm	16 Sq.mm	16 Sq.mm	20 Sq.mm
			output R,Y,B,N	10 Sq.mm	12 Sq.mm	16 Sq.mm	16 Sq.mm	20 Sq.mm
			Batt.360V	16 Sq.mm	16 Sq.mm	25 Sq.mm	35 Sq.mm	35 Sq.mm
			Earth & I/P-Neut	2.5 Sq.mm
Output	Power factor		lag	0.8
	voltage		V	230
	Voltage regulation		%	±1
	Frequency		Hz	50
	Frequency regulation		Hz	±0.05
	Waveform			Pure Sine Wave
	Transient Response		%	<8(10%-90%(Linear Load))
	Voltage Harmonic		%	<3(Linear Load)
	Over Load Capacity			100 to 110%:5min. 110 to 120 :2 min. 120 to 150 :30 sec. 150 to 300 :20-30 msec. >300 immediate
	Crest-Factor			3:1
	Receptacle			100A	100A	175A	175A	175A
Audible Warning	Battery Back-up Ending			intermittent
	OverLoad			Continuous
	Protection		Once	Output H/L-R,Y,B # Overload-R,Y,B #Output Short Circuit # Mains H/L-R,Y,B #Battery Over Voltage # Battery under Voltage.
	Mains High/Low
Display	LED			UPS On # Output L/H-R,Y,B,# Overload-R,Y,B # Batt.-H/L# Charging On # Main L/H-R,Y,B.
	Touch Screen Color Display			Input Output & Battery Parameter, Load Level,Working mode and Fault Status
Interface				RS232/USB Port,SNMP(Optional)
Others	Battery Start			Standard
	Cabinet Wheels			Standard
	Extended Battery Charging			Optional
	Static By Pass			Optional/Default Rotary Switch
Overall	Efficiency(AC/DC)		%	>90**(Full Load)
	Transfer Time		ms	0
	Temperature		° c	0-45
	Humidity		%	5-95(Non-Condensed)
	Dimension	Width	Inch	19	19	25	25	25
		Heigth	Inch	30	30	44	44	44
		Length	Inch	33	33	46.5	46.5	46.5
